CA-35RS Lightning Arrestor N Male Plug To N Female Coaxial 0-1GHZ 400W 50ohm DC-1000MHz N Connector 400W Protector Arrester 1

Certification : NONE,CE  1pc CA-35RS lightning arrester male and female head wireless module antenna with lightning arrester fastenerFeatures:This product adopts the principle of 1/4 short-circuit wavelength to achieve good lightning protection effect. The arrester has a solid structure, beautiful appearance and convenient installation.One end is connected to the antenna, and one end is connected to the feeder. The side of the arrester has a screw ring for grounding. It can be inserted into a thick copper wire and pressed tightly with a vise. Then the other end of the copper wire is connected to the lightning protection net on the top of the building. The contact must be sufficient.Specifications:requency Range:DC-1000MHzV.S.W.R≤1.1Loss ≤0.2dBWithstand power:400W PEPVoltage at discharge start:DC350V+-15%Discharge voltage of shock wave(1 x 40)uS:1,000VWithstand current of shock wave(1 x 40)uS:6,000ARepetitive discharge of shock wave(1 x 40)uS 500A,over 500 times:DC350V±20% Insulating resistance DC 100V:Over 10,000M ohmSize:7.5x4.5x2cmType:CA-35RSPackage Included:1xCA-35RS Lightning ArresterNotes:1.Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid.2.Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
